CFP 3375 Fire Suppression System with Pressure switch

Item #: CFP 3375
There are no reviews yet Write a review
Price: $2,290.00
    The product is in stock Availability: In Stock
    Usually ships In 2-4 Business Days

    Quantity:

    About This Item

    CFP 3375

    The CFP 3375 is the second largest of our Dry Chemical units. With it’s significant coverage reach this system can address much larger spaces. It is installed vertically and covers 15’x15’x15’. Larger and/or taller building offices, warehouses, work spaces, storage areas, industrial spaces, any space where there is a water restriction or lack of water capacity the CFP 3375 is used. Our CF-33 dry chemical agent is non-corrosive, non-conductive & non-toxic, making it a safe option for nearly any application.

    This Unit is self-activating. Each unit is designed to initiate automatically by means of a sprinkler head rated at 155ºF (68ºC). The temperature rating for each sprinkler head is stamped on the star shaped deflector in both Fahrenheit and Celsius measurements. The temperature of the sprinkler head is fixed and must be designated at the time of purchase. When the temperature rise to activate the Cease Fire® unit, the sprinkler head opens automatically and dispenses the entire contents in less than 10 seconds onto the fire and throughout the enclosure being protected. If the unit is equipped with the optional pressure switch, a signal is sent at the time of discharge to activate accessory equipment, such as an alarm.

    **Before Purchase Contact Us With Engineer Drawings So We Can Ensure The Proper Fire Suppression For Your Application**


    Contact Us For A Current Freight Quote On This Item


        Maximum Total Flood Volume15'x15'x15' = 3375ft³ / 4.57mx4.57mx4.57m =
        95.44m³
        Reach Coverage Area 15'x15' = 225ft² / 4.57mx4.57m = 20.88m²
        Temperature Rating -20°F to 120°F / -29°C to 49°C
        Cylinder Manchester 30# / Worthington 69#
        Diameter 12.25" / 31cm
        Height 19.56"+3.50 Coupling Assembly /
        50cm+8.90cm
        Capacity 30lbs / 13.61kg
        Unit Weight 61lbs / 27.67kg
        Ship Weight 65lbs / 29.48kg
        Approvals UL, ULC, CSFM, NYC #5754
        Propellant High Purity Compressed Dry Nitrogen
        Standard System Activation: 155° Fahrenheit / 68.3° Celsius
